2SC3950 NPN TRANSISTOR

2SC3950 NPN TRANSISTOR 5stuks

Maximum Collector Power Dissipation (Pc): 5 W

Maximum Collector-Base Voltage
Vcb
: 30 V

Maximum Collector-Emitter Voltage
Vce
: 20 V

Maximum Emitter-Base Voltage
Veb
: 3 V

Maximum Collector Current
Ic max
: 0.5 A

Max. Operating Junction Temperature (Tj): 150 °C

Transition Frequency (ft): 2000 MHz

Collector Capacitance (Cc): 6 pF

Forward Current Transfer Ratio (hFE), MIN: 30

• Maximum Collector Power Dissipation (Pc): 5 W

• Maximum Collector-Base Voltage |Vcb|: 30 V

• Maximum Collector-Emitter Voltage |Vce|: 20 V

• Maximum Emitter-Base Voltage |Veb|: 3 V

• Maximum Collector Current |Ic max|: 0.5 A

• Max. Operating Junction Temperature (Tj): 150 °C

• Transition Frequency (ft): 2000 MHz

• Collector Capacitance (Cc): 6 pF

• Forward Current Transfer Ratio (hFE), MIN: 30
